24V Weather Resistant Linear Bearing Link Drive Motor Assembly

Motor Type: 24V DC, 1/4 HP weather-resistant motor with linear bearing link drive Lift Range: Pumps from up to 225 feet total head (water level + vertical rise + 100′ equivalent for pressure) Enclosure: Weather-resistant aluminum housing for heat dissipation and outdoor protection Power Draw: 12 amps peak, 5–10 amps average, 15 amp fuse recommended Electrical Components: Includes relay, terminal block, and fuse holder with 15 amp automotive-style fuse Compatibility: Works with deep well pumps 100CA (225’ max lift), 125CA (150’ max lift), and 200CA (60’ max lift) cylinders. Works with shallow well pumps PHA-2-S-25 and PHA-47-S-25.
